S212-01

  • S212-01
  • Product Name:

    S212-01
  • Model No.:

    S212-01


Product Description

Key Features:
–  Dual S100 series side-by-side facing opposite directions
–  Opens/closes by pressing on top panel
–  Durable pneumatic movement and mechanical latching mechanism
–  AC power outlets available for US, Europe, and other major world markets
–  CE compliant
–  Colour: Black, Silver, by customize
–  Bezel: Rectangle
–  Finish: Brushed Aluminum





Model: S212-01
P/N: Bezel Colour Finish
212.0101 Rectangle Black Brushed Aluminum
212.0102 Rectangle Silver Brushed Aluminum





Specifications

AV & Data Electrical
Network: (3) RJ-45 F-M, 1.5m AC Power: (2) Universal F-M, 220-250VAC, 60Hz, 10A, 1.8m
Audio: (1) 3.5mm stereo F-M, 1.5m
VGA: (1) 15pin F-M, 1.5m

Mechanical Accessories
Panel size: 252x132mm Mounting screws and brackets
Cut out: 240.8x121.4mm, R=13 User Manual
Weight (approx.): 2.5kg
Shipping Weight(approx.): 4.5kg

Packing
1pc per box
box size:
4pcs in a carton
carton size:





Dimensions
