  • Product Name:

    S300-01H
  • Model No.:

    S300-01H


Product Description

Key Features:
–  Mounts into tabletop, provides single input plate
–  Opens/closes by pressing on top panel
–  Durable pneumatic movement and mechanical latching mechanism
–  AC power outlets available for US, Europe, and other major world markets
–  CE compliant
–  Colour: Black, Silver, by customize
–  Bezel: Rectangle, Elliptical
–  Finish: Brushed Aluminum, Matte





Model: S300-01H
P/N: Bezel Colour Finish
300.0161 Rectangle Black Brushed Aluminum
300.0162 Rectangle Black Matte
300.0163 Rectangle Silver Brushed Aluminum
300.0164 Rectangle Silver Matte
300.0165 Elliptical Black Brushed Aluminum
300.0166 Elliptical Black Matte
300.0167 Elliptical Silver Brushed Aluminum
300.0168 Elliptical Silver Matte





Specifications

AV & Data Electrical
Network: (1) RJ-45 F-M AC Power: (1) Universal F-M, 220-250VAC, 60Hz, 10A
Audio: (1) 3.5mm stereo F-M
VGA: (1) 15pin F-M
HDMI: (1) 19pin F-M

Mechanical Accessories
Panel size: 157x132mm Mounting screws and brackets
Cut out: 146.4x121mm User Manual
Weight (approx.): 1.5kg
Shipping Weight(approx.): 2.5kg

Packing
1pc per box
box size: 210x210x210mm
8pcs in a carton
carton size: 450x450x450mm



Dimensions
