  • Product Name:

    S100-04FR
  • Model No.:

    S100-04FR


Product Description

Key Features:
–  Mounts into tabletop, provides single input plate
–  Opens/closes by pressing on top panel
–  Durable pneumatic movement and mechanical latching mechanism
–  AC power outlets available for US, Europe, and other major world markets
–  CE compliant

–  Colour: Black, Silver, by customize
–  Bezel: Square, Round
–  Finish: Brushed Aluminum, Matte





Model: S100-04FR
P/N: Bezel Colour Finish
100.0421 Square Black Brushed Aluminum
100.0422 Square Black Matte
100.0423 Square Silver Brushed Aluminum
100.0424 Square Silver Matte
100.0425 Round Black Brushed Aluminum
100.0426 Round Black Matte
100.0427 Round Silver Brushed Aluminum
100.0428 Round Silver Matte





Specifications

AV & Data Electrical
Network: (2) RJ-45 F-M AC Power: (1) NF C61-314 F-M, 250VAC, 60Hz, 16A

Mechanical Accessories
Panel size: 132x132mm Mounting screws and brackets
Cut out: 121x121mm User Manual
Weight (approx.): 1.2kg
Shipping Weight(approx.): 2.0kg

Packing
1pc per box
box size: 210x210x210mm
8pcs in a carton
carton size: 450x450x450mm
